Toyota Auris 1.4 D4D Engine Replacement - Compare Prices & Get Quotes
Get quotes today from trusted UK Toyota Auris 1.4 D-4D engine specialists. Compare prices on reconditioned, rebuilt and used 1ND-TV engines with warranty - supply and fit available nationwide.
Supply & Fit Available
12-Month Warranty
Nationwide Delivery
100+ Suppliers
From TV - from £1,500 to £2,200
Used from £800 · Reconditioned from £1,500 · Common codes: 1ND-TV
From £800
Tested, bare/short engine
From £1,500
Rod bearings addressed, tested
From quote
Upgraded bearings, full teardown, revised valvetrain
Secure enquiry - no spam, no pressure. Genuine quotes only from vetted UK Toyota Auris 1.4 D-4D specialists.
3 Simple Steps3 Simple Stepsto Finding the Best Toyota Auris 1.4 D-4D Replacement Engineto Finding the Best Toyota Auris 1.4 D-4D Replacement Engine
Most replacements completed within 3-5 days.
Variant HistoryToyota Auris 1.4 D-4D - Engine History & Specs at a Glance
The 1.4 D-4D brought Toyota's common-rail diesel technology to the Auris range, offering a fuel-efficient and torquey alternative to the petrol engines. Powered exclusively by the 1ND-TV engine, it delivered 90hp and strong low-end pulling power ideal for urban and motorway driving.
Variant HistoryToyota Auris 1.4 D-4D - Engine History & Specs at a Glance
The 1.4 D-4D brought Toyota's common-rail diesel technology to the Auris range, offering a fuel-efficient and torquey alternative to the petrol engines. Powered exclusively by the 1ND-TV engine, it delivered 90hp and strong low-end pulling power ideal for urban and motorway driving.
Toyota Auris 1.4 D-4D
Fuel TypeDiesel
Engine Size1.4L (1,364cc)
Power Output90hp (66kW) @ 4,000rpm; 205Nm torque @ 2,000-2,800rpmEngine History Timeline
1.4 D-4D introduced with first-generation Auris (E150); 1ND-TV 1.4-litre common-rail diesel 90hp, five-speed manual transmission
Facelift; 1.4 D-4D continues with emissions updates
Second-generation Auris (E180) launched; 1ND-TV engine carries over with Euro 5 emissions compliance
Business Edition trim introduced with 1.4 D-4D option
1.4 D-4D phased out as Auris replaced by Corolla; production ends December 2018
Key Specs Snapshot
Fuel TypeDieselEngine Size1.4L (1,364cc)Power Output90hp (66kW) @ 4,000rpm; 205Nm torque @ 2,000-2,800rpmYears Produced2007-2018 (UK)Every engine fitted to the Toyota Auris 1.4 D-4D is covered below, with UK rebuilt pricing and known failure points.
Toyota Auris 1.4 D-4D Engine Codes - Specifications & Replacement CostToyota Auris 1.4 D-4D Engine Codes - Specifications & Replacement Cost
1.4L D-4D Turbo Diesel (2007-2018)
Power Output90hp (66kW) @ 4,000rpm; 205Nm torque @ 2,000-2,800rpmYears Fitted2007-2018 (E150 and E180 Auris)
Compatible Trim Levels
- T2
- TR
- Icon
- Business Edition
- Excel
- Design
Find your exact engine code, specs and UK replacement cost guide.
Used
Tested, ready-to-fit engine
£800-£1,400
Reconditioned
Addressed known issues, tested
£1,500-£2,000
Rebuilt
Full teardown, upgraded internals
£1,800-£2,200
Common Failure
EGR valve clogging from soot buildup is a widely reported issue on the 1ND-TV, typically appearing from 60,000-80,000 miles. Fuel system overpressure (fault code P1229) can also occur, often related to injector or high-pressure pump wear.
The 1ND-TV engine powering the Toyota Auris 1.4 D-4D is a robust and fuel-efficient diesel unit - many have covered 150,000+ miles with proper maintenance. However, age and mileage bring three well-documented failure patterns. Rebuilt engines through EnginesMarket include upgraded components addressing the original failure points, plus a minimum 12-month unlimited-mileage warranty.
Why the Toyota Auris 1.4 D-4D 1ND-TV Loses Power
Affected Vehicles
Toyota Auris 1.4 D-4D (1ND-TV, all years)
Typical Failure Mileage
60,000-80,000 miles
Root Cause
Like many modern diesels, the EGR (exhaust gas recirculation) valve can become clogged with soot buildup over time. This restricts airflow, causing rough idling, reduced power, poor fuel economy and potentially triggering the Check Engine light.
Why It Happens
Like many modern diesels, the EGR (exhaust gas recirculation) valve can become clogged with soot buildup over time. This restricts airflow, causing rough idling, reduced power, poor fuel economy and potentially triggering the Check Engine light.
Dealer (parts + labour)
£200-£350
Specialist (parts + labour)
£100-£200
What it involves
Remove and clean EGR valve, intake and throttle body
Suitability
Suitable for first occurrence; may need repeating
1 - 2 daysDealer (parts + labour)
£400-£700
Specialist (parts + labour)
£250-£450
What it involves
Replace EGR valve with new OEM or quality aftermarket unit
Suitability
Recommended if cleaning doesn't resolve the fault
1 - 2 daysDealer (parts + labour)
£2,500-£3,500
Specialist (parts + labour)
£1,800-£2,200 (matches Section 4 rebuilt figure for this code)
What it involves
Supply & fit complete engine with new EGR components, 12-month warranty
Suitability
Required if EGR failure has caused related damage
1 - 2 daysAll prices are indicative UK market ranges based on current UK specialist supplier data.| Repair Tier | Dealer (Parts + Labour) | Specialist (Parts + Labour) | What It Involves | Suitability | Estimated Time |
|---|---|---|---|---|---|
 EGR valve cleaning Minor | £200-£350 | £100-£200 | Remove and clean EGR valve, intake and throttle body | Suitable for first occurrence; may need repeating | 1 - 2 days |
 EGR valve replacement Best Value | £400-£700 | £250-£450 | Replace EGR valve with new OEM or quality aftermarket unit | Recommended if cleaning doesn't resolve the fault | 1 - 2 days |
Full Replacement - rebuilt/reconditioned engine Best Value | £2,500-£3,500 | £1,800-£2,200 (matches Section 4 rebuilt figure for this code) | Supply & fit complete engine with new EGR components, 12-month warranty | Required if EGR failure has caused related damage | 1 - 2 days |
Vehicle Value Check
Vehicle Value Check
A typical 2007-2018 Auris 1.4 D-4D is worth approximately £1,500-£5,000 depending on condition, mileage and trim. With rebuilt engine supply costs starting around £1,800-£2,200, replacement cost may represent 40-100% of vehicle value on lower-value examples. For cars worth under £2,000, EGR cleaning or replacement is often the more financially sensible route.
Our Recommendation
Our Recommendation
Start with EGR cleaning - it's inexpensive and often resolves the issue. If the fault returns within 12 months, replace the EGR valve. Regular motorway driving helps reduce soot buildup, while short urban trips accelerate EGR clogging.
Don't Let Engine Failure Write Off Your Toyota Auris 1.4 D-4D
Whether you're dealing with EGR clogging, fuel system issues or coolant loss, a rebuilt 1ND-TV engine from our network of UK specialists includes upgraded components addressing the original failure points. Every engine carries a minimum 12-month unlimited-mileage warranty, with nationwide delivery and supply & fit options available. Compare quotes today - it's free, fast and obligation-free.
Compare Toyota Auris 1.4 D-4D EGR repair costs
12-Month Minimum
UK Specialists Vetted
Best Price GuidanceImportant Information
Important Information
Toyota Auris 1.4 D-4D Engine ReplacementFrequently Asked Questions
Question 1How much does a Toyota Auris 1.4 D-4D engine replacement cost in the UK-
A rebuilt 1ND-TV engine for your Toyota Auris 1.4 D-4D typically costs £1,800-£2,200 supply-only, with used engines available from £800-£1,400. Fitting adds approximately £520-£650 for indie labour (8-10 hours at £65/hr).
- Used 1ND-TV: £800-£1,400
- Reconditioned: £1,500-£2,000
- Rebuilt with warranty: £1,800-£2,200
- Supply & fit total: from around £1,300 for a used unit, up to £2,800+ for a rebuilt engine fitted
Question 2What are the common signs of 1ND-TV engine failure in a Toyota Auris 1.4 D-4D-
The most frequently reported issues across the Toyota Auris 1.4 D-4D range are:
- Rough idling, power loss and poor fuel economy from EGR valve clogging
- Rough running, hard starting and fuel system overpressure (P1229) from injector or pump wear
- Gradual coolant loss without visible leaks from EGR cooler failure
Question 3Is it worth replacing the engine in a Toyota Auris 1.4 D-4D-
This depends on your car's condition and value. A typical 2007-2018 Auris 1.4 D-4D is worth £1,500-£5,000 depending on condition and mileage.
- If your car is worth under £2,000: a used engine (£800-£1,400 fitted) or targeted repair is usually the better financial decision
- If your car is worth over £3,000: a rebuilt engine with 12-month warranty and upgraded components is a sound investment
- If the car has sentimental value or you plan to keep it long-term: the warranty and reliability of a rebuilt unit often justifies the premium
Question 4How long does a Toyota Auris 1.4 D-4D engine replacement take-
A typical Toyota Auris 1.4 D-4D engine replacement takes 1-2 working days at a specialist workshop (8-10 hours labour). Allow additional time for parts delivery if your chosen engine isn't in stock locally.
-> Book your Toyota Auris 1.4 D-4D engine replacement with a trusted UK specialistQuestion 5What's the difference between the Toyota Auris 1.4 D-4D and the 2.0 D-4D-
The 1.4 D-4D (1ND-TV) and 2.0 D-4D (1AD-FTV / 2AD-FTV) share Toyota's D-4D common-rail diesel architecture but differ significantly:
- **1.4 D-4D (1ND-TV):** 1,364cc, 90hp, 205Nm, simpler SOHC design, no DPF on early models
- **2.0 D-4D (1AD-FTV):** 1,998cc, 124hp, 310Nm, more complex DOHC design, DPF-equipped
Question 6Is the Toyota Auris 1.4 D-4D ULEZ compliant-
The 1ND-TV engine in the Auris 1.4 D-4D meets Euro 4 (pre-2010) or Euro 5 (2010-2018) emissions standards depending on year. For London ULEZ:
- Euro 4 diesel (pre-2010) is NOT ULEZ compliant
- Euro 5 diesel (2010-2015) is NOT ULEZ compliant
- Euro 6 diesel (2015-2018) IS ULEZ compliant
Why Choose UsCompare Toyota Auris 1.4 D-4DEngine PricesToday
200+ Toyota Auris 1.4 D-4D 1ND-TV engines supplied through our network
12-Month Warranty on every rebuilt Auris 1.4 D-4D engine
Nationwide UK delivery
supply & fit available
Whether you need a used 1ND-TV to keep costs down or a fully rebuilt engine with upgraded components and 12-month warranty, comparing quotes through EnginesMarket is free, fast and carries no obligation. Enter your registration above and let our network of UK Toyota Auris 1.4 D-4D specialists compete for your business.
Enter your registration
and get matched with verified Toyota Auris 1.4 D-4D specialists.
