Porsche Carrera GT 980/01 V10 Specialist Engine ReplacementCompare Quotes

A rebuilt M80.01 V10 for the Carrera GT typically costs £45,000-£120,000 supply-only in the UK, depending on specification, core condition and rebuild depth. Supply & fit adds £12,000-£28,000 labour.

• Rebuilt M80.01 units range £45k-£120k supply-only
• Supply & fit labour adds £12k-£28k depending on chassis condition
• Core charge refunds apply when returning your damaged engine
• Matching-numbers rebuilds command premium pricing for collectors

The impulse/reference sensor (P/N 931 606 021 00) is the most documented failure, causing no-start above 4000rpm on early-production M80.01 V10 units.

• Sensor P/N 931 606 021 00 suffers heat-induced signal loss
• Failure causes no-start above 4000rpm, not total engine seizure
• Replacement requires transmission removal due to bellhousing location
• Later-production units received revised sensor mounting protocol

No - the mid-engine packaging of the Carrera GT requires full engine removal to access the PCCC ceramic clutch assembly for replacement or service.

• PCCC clutch sits between engine and transaxle in mid-engine layout
• Engine removal is mandatory for clutch access on all 2004-2006 units
• Labour for clutch-only service typically £18k-£32k at UK specialists
• Bundled engine + clutch rebuild offers better long-term value

For a £400k+ asset, a rebuilt M80.01 with upgraded components and warranty typically offers superior long-term value versus a used unit of unknown history.

• Rebuilt engines include upgraded wear parts and 12-month warranty
• Used units carry unknown service history and no upgrade benefits
• Collector value favours documented rebuilds over salvage swaps
• Core charge refunds reduce effective rebuilt engine cost

A full M80.01 supply & fit typically takes 3-6 weeks at a UK specialist, depending on engine availability, chassis condition and ancillary work required.

• Engine removal and prep: 5-7 working days
• Rebuilt engine lead time: 2-4 weeks if not in stock
• Installation, calibration and testing: 3-5 working days
• Carbon-fibre chassis inspection may extend timeline

Yes - every M80.01 engine supplied through EngineMarket includes a minimum 12-month unlimited mileage warranty from UK V10 specialists, with 24-month options available on select rebuilt units.

• Minimum 12-month unlimited mileage warranty standard
• Warranty covers parts and labour at any UK specialist in network
• 24-month coverage available on premium rebuilt specifications
• Matching-numbers rebuilds include documentation warranty

The Porsche Carrera GT exclusively uses the M80.01 5.7L naturally aspirated V10 engine code across all 2004-2006 production years and variants.

• M80.01 is the sole engine code for all Carrera GT units
• Derived from Porsche LMP2000 racing engine heritage
• Features dry-sump lubrication and carbon-fibre integration
• No other engine codes were ever fitted to UK-market Carrera GTs

Yes - M80.01 engines are largely interchangeable across 2004-2006 Carrera GT production, though DME calibration and sensor compatibility must be verified by a V10 specialist.

• M80.01 block and heads are interchangeable across all years
• Later-spec impulse sensors may require DME software update
• Carbon-fibre mount points must be inspected for APA3 recall compliance
• Specialist calibration required post-installation for optimal performance

The M80.01 V10 requires Porsche-approved 10W-60 fully synthetic oil meeting A40 specification, with a dry-sump capacity of 10.5 litres including filter and lines.

• Use Porsche A40-approved 10W-60 fully synthetic oil only
• Total dry-sump capacity: 10.5 litres including filter and lines
• Oil change interval: 10,000 miles or 12 months, whichever comes first
• Track use requires pre- and post-session oil level verification

The M80.01 V10 is engineered for performance, not daily commuting; reliability depends on specialist maintenance, avoiding short trips, and proactive monitoring of known failure points.

• M80.01 is robust when maintained by V10 specialists only
• Avoid short trips that prevent oil/system warm-up
• Monitor impulse sensor and oil pressure via dedicated gauges
• Annual specialist inspection recommended regardless of mileage
