Mercedes Benz GLA Class GLA 200 d / GLA 220 d Engine ReplacementCompare Prices & Get Quotes
Get quotes today from trusted UK Mercedes Benz GLA Class 200 d and 220 d engine specialists. Compare prices on reconditioned, rebuilt and used OM654 2.0-litre diesel engines - supply & fit available nationwide for both front-wheel drive and 4MATIC variants.
Supply & Fit Available
12-Month Warranty
Nationwide Delivery
100+ Suppliers
From £2,500 to £6,000
Used from £1,800 · Reconditioned from £3,200 · Common codes: OM654.920
From £1,800
Tested, bare/short engine
From £3,200
Rod bearings addressed, tested
From quote
Upgraded bearings, full teardown, revised valvetrain
Secure enquiry - no spam, no pressure. Genuine quotes only from vetted UK Mercedes Benz GLA Class diesel specialists.
3 Simple Steps3 Simple Stepsto Finding the Best Mercedes Benz GLA Class GLA 200 d / GLA 220 d Replacement Engineto Finding the Best Mercedes Benz GLA Class GLA 200 d / GLA 220 d Replacement Engine
Most replacements completed within 3-5 days.
Variant HistoryMercedes Benz GLA Class GLA 200 d / GLA 220 d - Engine History & Specs at a Glance
The Mercedes Benz GLA 200 d and GLA 220 d introduced the all-new OM654 2.0-litre four-cylinder diesel engine with the second-generation H247 GLA in 2020, replacing the OM651 2.1-litre diesel from the previous X156 generation with a lighter, more efficient and more refined powertrain.
Variant HistoryMercedes Benz GLA Class GLA 200 d / GLA 220 d - Engine History & Specs at a Glance
The Mercedes Benz GLA 200 d and GLA 220 d introduced the all-new OM654 2.0-litre four-cylinder diesel engine with the second-generation H247 GLA in 2020, replacing the OM651 2.1-litre diesel from the previous X156 generation with a lighter, more efficient and more refined powertrain.
Mercedes Benz GLA Class GLA 200 d / GLA 220 d
Fuel TypeDiesel
Engine Size2.0L (1,949cc)
Power Output Range150-190hp across the GLA 200 d and GLA 220 dEngine History Timeline
H247 GLA launched with OM654 DE20 GA 2.0L diesel available as GLA 200 d (150hp, 320Nm) and GLA 220 d (190hp, 400Nm)
8G-DCT dual-clutch transmission introduced as standard on 200 d and 220 d variants
Euro 6d emissions compliance with AdBlue SCR system
H247 facelift OM654 diesel engines continue unchanged with 48V mild-hybrid not applied to diesel range
Key Specs Snapshot
Fuel TypeDieselEngine Size2.0L (1,949cc)Power Output Range150-190hp across the GLA 200 d and GLA 220 dTorque Range320-400NmYears Produced2020-presentEvery OM654 diesel engine fitted to the Mercedes Benz GLA Class 200 d and 220 d is covered below, with UK rebuilt pricing and known failure points from real owner experience.
Mercedes Benz GLA Class 200 d / 220 d Engine Codes - Specifications & Replacement CostMercedes Benz GLA Class 200 d / 220 d Engine Codes - Specifications & Replacement Cost
2.0L Diesel (2020-present)
Power OutputGLA 200 d: 150 hp (110 kW) @ 3,400-4,400 rpm; GLA 220 d: 190 hp (140 kW) @ 3,800 rpmTorqueGLA 200 d: 320 Nm @ 1,400-3,200 rpm; GLA 220 d: 400 Nm @ 1,600-2,600 rpmDisplacement1,949ccConfigurationInline-4, DOHC, turbocharged, common-rail direct injection (fourth generation) with piezo injectors up to 2,050 barYears Fitted2020-present
Compatible Trim Levels
- GLA 200 d
- GLA 200 d 4MATIC
- GLA 200 d AMG Line
- GLA 220 d
- GLA 220 d 4MATIC
- GLA 220 d AMG Line
Find your exact engine code, specs and UK replacement cost guide.
Used
Tested, ready-to-fit engine
£1,800-£3,500
Reconditioned
Addressed known issues, tested
£3,200-£5,000
Rebuilt
Full teardown, upgraded internals
£2,500-£6,000
Common Failure
The OM654 is generally reliable, but EGR cooler thermal cracking is a documented issue - coolant loss without visible external leakage is a key symptom. AdBlue system crystallisation and turbocharger issues from contaminated crankcase ventilation have also been reported.
The Mercedes Benz GLA 200 d and 220 d rely on the OM654 2.0-litre modular diesel - a lightweight, all-aluminium engine praised for refinement and efficiency, but not without its vulnerabilities. EGR cooler thermal cracking, AdBlue system failures, and turbocharger issues dominate replacement demand, particularly on post-2020 H247 models. Every rebuilt engine supplied through EnginesMarket includes upgraded components designed to address the original failure point - plus a minimum 12-month unlimited mileage warranty. Below we break down the most common GLA 200 d and 220 d engine failures, what they cost to fix, and when replacement is the smarter financial decision.
Why the GLA 200 d / 220 d Loses Coolant
Affected Vehicles
Mercedes Benz GLA Class GLA 200 d, GLA 220 d (OM654.920, 2020-present)
Typical Failure Mileage
40,000 - 70,000 miles
Root Cause
The OM654's exhaust gas recirculation (EGR) cooler is subject to thermal cycling between exhaust gas temperatures and coolant. Differential expansion causes microscopic cracks in the cooler matrix, allowing coolant to be drawn into the intake manifold. The result is progressive coolant loss, white exhaust smoke, and eventually hydrolock if ignored.
Why It Happens
The OM654's exhaust gas recirculation (EGR) cooler is subject to thermal cycling between exhaust gas temperatures and coolant. Differential expansion causes microscopic cracks in the cooler matrix, allowing coolant to be drawn into the intake manifold. The result is progressive coolant loss, white exhaust smoke, and eventually hydrolock if ignored.
Dealer (parts + labour)
£1,100-£1,700
Specialist (parts + labour)
£600-£950
What it involves
Replace EGR cooler with updated design, flush cooling system, reset adaptions
Suitability
40k-70k miles. Viable if caught early with no secondary damage
1 - 2 daysDealer (parts + labour)
£1,600-£2,300
Specialist (parts + labour)
£1,000-£1,500
What it involves
EGR cooler replacement plus intake manifold cleaning to remove coolant residue and carbon
Suitability
40k-70k miles. Required if coolant has fouled intake valves
1 - 2 daysDealer (parts + labour)
£5,000-£7,500
Specialist (parts + labour)
£2,800-£5,500
What it involves
Supply & fit of rebuilt OM654 engine with updated EGR cooler, intake manifold, and emissions system components
Suitability
80,000+ mile lifespan. Necessary when coolant ingestion has bent a conrod or caused cylinder bore scoring
1 - 2 daysAll prices are indicative UK market ranges based on current UK specialist supplier data.| Repair Tier | Dealer (Parts + Labour) | Specialist (Parts + Labour) | What It Involves | Suitability | Estimated Time |
|---|---|---|---|---|---|
 Minor - EGR Cooler Replacement Minor | £1,100-£1,700 | £600-£950 | Replace EGR cooler with updated design, flush cooling system, reset adaptions | 40k-70k miles. Viable if caught early with no secondary damage | 1 - 2 days |
 Intermediate - Cooler Plus Intake Cleaning Best Value | £1,600-£2,300 | £1,000-£1,500 | EGR cooler replacement plus intake manifold cleaning to remove coolant residue and carbon | 40k-70k miles. Required if coolant has fouled intake valves | 1 - 2 days |
Full Replacement - Rebuilt Engine Best Value | £5,000-£7,500 | £2,800-£5,500 | Supply & fit of rebuilt OM654 engine with updated EGR cooler, intake manifold, and emissions system components | 80,000+ mile lifespan. Necessary when coolant ingestion has bent a conrod or caused cylinder bore scoring | 1 - 2 days |
Vehicle Value Check
Vehicle Value Check
A typical H247 GLA 200 d or 220 d is worth £18,000-£35,000 depending on age, mileage and condition - the full replacement cost of £2,800-£5,500 is modest relative to vehicle value, making a specialist rebuilt engine a sound investment. For vehicles worth under £15,000, evaluate repair options first.
Our Recommendation
Our Recommendation
On a newer GLA 200 d or 220 d, the EGR cooler replacement at a specialist (£600-£950) is a no-brainer. However, if your car has already overheated or shown misfire symptoms, pay for a borescope inspection before committing to repairs - bent rods are not always immediately obvious. Rebuilt OM654 units with upgraded EGR systems are increasingly common as these cars age out of manufacturer warranty.
Don't Let Engine Failure Write Off Your Mercedes Benz GLA 200 d or GLA 220 d
A failed engine doesn't have to mean the end of your GLA diesel. Whether you're dealing with an OM654 EGR cooler failure, AdBlue system issues, or timing chain wear, EnginesMarket makes it simple to compare prices from trusted UK Mercedes Benz GLA Class specialists. Every rebuilt engine in our network includes upgraded components designed to address the original failure point, a minimum 12-month unlimited mileage warranty, and nationwide delivery with supply & fit options available.
Get quotes for OM654 EGR cooler repair and rebuilt engine options for your GLA 200 d / 220 d
12-Month Minimum
UK Specialists Vetted
Best Price GuidanceImportant Information
Important Information
"All prices are indicative UK market ranges based on historical quote data and repair requests from our network of engine specialists. Dealer pricing is estimated based on published main dealer labour rates and genuine OEM parts pricing. Specialist pricing reflects actual quote data from EnginesMarket's UK network. Actual costs vary depending on damage severity, vehicle condition, variant, and workshop location within the UK. Use our free comparison tool to get tailored quotes for your specific Mercedes Benz GLA Class 200 d or 220 d. Every engine supplied through EnginesMarket carries a minimum 12-month unlimited mileage warranty - always confirm exact terms with your chosen supplier."
Mercedes Benz GLA Class 200 d / 220 d Engine ReplacementFrequently Asked Questions
Question 1How much does it cost to replace a GLA 200 d or GLA 220 d engine in the UK-
A GLA 200 d or GLA 220 d engine replacement typically costs between £2,500 and £6,000 depending on condition type and whether fitting is included. OM654 2.0-litre diesel units range from £2,500 to £6,000 supply only.
- Rebuilt OM654 (GLA 200 d / 220 d): £2,500-£6,000 supply only
- Reconditioned units: £3,200-£5,000
- Used engines from breakers: £1,800-£3,500 but higher risk
- Labour for supply & fit adds £800-£1,500 to any engine price
Question 2Is the OM654 engine in the GLA 200 d and 220 d reliable-
The OM654 is a highly refined and efficient engine, praised for its lightweight all-aluminium construction and reduced friction losses. However, it has several well-documented issues that owners should be aware of.
- EGR cooler thermal cracking causing coolant loss
- AdBlue system crystallisation on urban-driven vehicles
- Timing chain and injector issues on higher-mileage units
- With regular maintenance and long journeys, 150,000+ miles is realistic
Question 3What are the signs of OM654 EGR cooler failure in a GLA diesel-
The OM654's EGR cooler typically fails between 40,000-70,000 miles, with several warning signs.
- Coolant level dropping with no visible external leak
- White smoke from the exhaust
- Check engine light illuminated
- Decrease in engine performance and rough idle
- Increased fuel consumption
Question 4Should I repair or replace my GLA 200 d or 220 d engine-
Repair if the failure is isolated (e.g., EGR cooler, AdBlue dosing module, injectors). Replace if there's bottom end damage, bore scoring, or catastrophic timing chain failure.
- EGR cooler replacement at specialist: £600-£950 - excellent value if caught early
- AdBlue dosing module replacement: £500-£800 - sensible repair for urban-driven cars
- Full OM654 rebuild: £2,800-£5,500 - for catastrophic failure or 100k+ miles
- Given GLA 200 d / 220 d values (£18,000-£35,000), a rebuilt engine is typically good value
Question 5How do I know which engine code my GLA 200 d or 220 d has-
Check your vehicle log book (V5C) for the engine number, which includes the engine code prefix.
- V5C log book shows full engine number with code prefix
- Engine code stamped on cylinder block
- GLA 200 d (2020-present): OM654.920 (2.0L diesel, 150hp)
- GLA 220 d (2020-present): OM654.920 (2.0L diesel, 190hp)
- Service history documents list engine type
Question 6Can I fit a used GLA 200 d or 220 d engine myself-
We strongly advise against DIY fitting on a GLA diesel. The complex emissions systems, 8G-DCT gearbox alignment, and ECU coding requirements demand specialist equipment and expertise.
- 8G-DCT transmission alignment requires specialist knowledge
- AdBlue and SCR system calibration needed
- ECU coding and immobiliser synchronisation required
- Specialist supply & fit costs £800-£1,500 - worth every penny
Question 7What warranty comes with a reconditioned GLA 200 d or 220 d engine-
Every engine supplied through EnginesMarket carries a minimum 12-month unlimited mileage warranty, with many specialists offering 24-month coverage on OM654 rebuilds. This includes parts and labour for any manufacturing defect or installation error.
- 12-month unlimited mileage is the minimum standard
- OM654 rebuilds often include 24-month warranty
- All warranties cover parts, labour, and MOT compliance
- Extended warranties available at point of purchase
Why Choose UsCompare Mercedes Benz GLA Class 200 d / 220 dEngine PricesToday
100+ GLA diesel engines supplied through our network
12-Month Warranty on every rebuilt GLA 200 d and 220 d engine
Nationwide UK delivery
supply & fit available
Comparing quotes for your Mercedes Benz GLA Class 200 d or 220 d engine replacement is completely free and carries no obligation - enter your registration above, receive tailored prices from UK specialists who know the OM654 modular diesel engine inside out, and get back on the road with confidence. Every rebuilt engine is backed by a minimum 12-month unlimited mileage warranty.
Enter your registration
and get matched with verified Mercedes Benz GLA Class GLA 200 d / GLA 220 d specialists.
